GFC Series Fiberglass Side Mount Sand Filter
| OEM | Available |
| Sample | Charge |
| Port | Huangpu, Guangzhou |
| Payment | T/T |
| Place of Origin | China |
| Shipping | Sea freight |
| Supply Ability | 10000 pieces per Month |
- Overview
- Recommended Products
- Polyester reinforced with fiberglass filter tank
- Max operating pressure 36psi/2.5bar
- Max temperature of43°C (109°F)
- Universal standard of union connection provided
- Suggested size of media:1-2mm
Description:
The GFC series tanks are non-corrosive, gel-coated glass fiber tanks with a smooth surface that can adapt to different climates. The surface of the tank is treated with sun protection, allowing it to operate in outdoor sunlight for a long time, making it suitable for residential and commercial swimming pools.
Product Details:
| Matrial | Fiberglass |
| Color | Green |
| Warraty | 1 Year |
| Suggested Size of Media | 1.0-2.0mm |
Specifications:
| Model | Filter Area(㎡) | Valve Connections | Max Flow Rate | Gravel(kg) | A mm | B mm |
| GFC500 | 0.2 | 1.5inch | 10.0 m³/h | 100 | 535 | 790 |
| GFC650 | 0.33 | 1.5 inch | 16.5 m³/h | 150 | 650 | 880 |
| GFC750 | 0.44 | 2 inch | 22.1 m³/h | 250 | 750 | 1070 |
| GFC800 | 0.5 | 2 inch | 25.0 m³/h | 350 | 800 | 1150 |
| GFC900 | 0.64 | 2 inch | 31.8 m³/h | 375 | 900 | 1200 |
Highlight Features:
Applications:
Swimming Pool Filtration
Residential swimming pools
Hotel & resort pools
Commercial swimming pools
SPA & wellness facilities
Indoor and outdoor pools
